SwemaFlow 4001 Luftstromhaube
SwemaFlow 4001 is ideal for testing, adjusting and balancing (TAB) of exhaust and supply air flows.
The proven Swema principle, a network of hot wires, provides accurate readings over the entire measuring range. The hot wires together with the counter pressure method and the larger hood make it suitable for supply air, including airflows from angled outlets.
The measured values can be saved and transferred to the PC.
Features and Benefits of the Gaussmeter 5270
- Supply and exhaust air flow
- 3...1500 l/s, 7...3100 cfm
- High accuracy and stability
- Memory
- temperature
- barometer
- Density compensation
- True or standard flow
- EN 16211, EN 12599 compliant
SPECIFICATION SWEMAFLOW 4001
| Measuring range | |
|---|---|
| Airflow | 3...1500l/s, 10,8...5400m³/h, 7...3100cfm |
| Temperature | 0...50°C, 32...122°F |
| Barometer | 600...1200hPa, 18...35 inHg |
| Measurement inaccuracy | |
|---|---|
| Airflow | ±3.5% of reading, min. ±0.5 l/s, min. ±1.1 cfm at 20–25 °C |
| Temperature | ±0,6 °C <50 l/s, ±0,4 °C >50 l/s |
| ±1,1 °F <106 cfm, ±0,7 °F >106 cfm | |
| Barometer | ±3.5hPa, ±0.1inHg |
